Brand: Avante
Type: New Avante Brand Monitors
Web ID: 36125
Product Number: 60145TCO2ARS
REQUEST QUOTE

Need help choosing?
Ask an Expert +1 (504) 701-3026

Listing Terms & Conditions

All product and company names are trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement or sponsorship by them.

DETAILS

Enhance workflow efficiency with our all-encompassing monitoring solution

This latest addition to the Waveline Series presents a comprehensive monitoring solution, capable of overseeing five agents (HAL, ISO, ENF, SEV, & DES), and accompanied by a fleet of standardized accessories that facilitate seamless transitions between machines. The Avante Waveline EZ MAX 2 Anesthesia Monitor is a multi-parameter patient monitor, equipped with a high-resolution touchscreen as a standard feature. Through the monitor's user-friendly menu interface, clinicians can effortlessly tailor the display to suit various care settings. The EZ MAX 2 also incorporates exclusive algorithms for ECG, SpO2, and NIBP, thereby enhancing monitoring capabilities. It is available with either mainstream or sidestream EtCO2 options, along with additional anesthetic gas parameters for monitoring.

For more information about the Avante Waveline EZ MAX 2 Anesthesia Monitor, please contact an Avante representative today.

Features

· Muti-parameter patient monitor comes standard with: 3/5-lead ECG, HR, RESP, SpO2, NIBP, PR, 2-TEMP

· High-resolution, 12.1-inch touchscreen

· Multiple display modes are customized for any setting: Standard display, large font, trend view, OxyCRG, bed-to-bed

· Intuitive shortcut menu allows clinicians to simplify setup

· Reliable monitoring algorithms optimized for a wide range of patients:

o ISEAPâ„¢ ECG: arrhythmia detection, pacemaker detection, heartrate measurement

o iMATâ„¢ SpO2: outstanding motion resistance and low perfusion resistance performance

o iCUFSâ„¢ NIBP: cardiac patients, hypertensive patients, neonatal patients

· Optional: Mainstream or sidestream EtCO2

· Position the EZ MAX 2 easily with the onboard bed rail hook or use with a wall mount or rolling stand

· Quiet, no fan design and night mode allow the monitor to blend seamlessly into the patient care setting

· Waterproof and dustproof keyboard design

· Comes standard with a thermal recorder

· Optional parameters include 2-IBP, Sidestream CO2, Respironics CO2, Nellcor OxiMax™ SpO2, Omron NIBP

· Monitors Anesthetic Agents when paired with integrated gas module

· Monitors 5 Agent IDs: HAL, ISO, ENF, SEV, & DES

Ask your Avante representative for details!

SPECIFICATIONS

Physical Specifications

  • Monitor Dimensions: 12.9 in (328 mm) W x 11.2 in (285 mm) H x 6.2 in (158 mm) D
  • Weight: < 10 lb (< 4.5 kg)
  • Display: 12.1 in color TFT touchscreen, resolution 800 x 600

Operating Specifications

  • Battery Operating Time (2500 mAh): ≥ 3.5h
  • Battery Operating Time (5000 mAh): ≥ 7h
  • Battery Charge Time (2500 mAh): ≤ 3.5 h (100% charge) | ≤ 3.2 h (90% charge)
  • Battery Charge Time (5000 mAh): ≤ 6 h (100% charge) | ≤ 5.4 h (90% charge)
  • Recording Types: Continual real-time recording, 8-second real-time recording, Trend graph recording, Trend table recording, NIBP review recording, Arrhythmia review recording, Alarm review recording, Drug calculation titration recording, Hemodynamic calculation result recording, Oxygenation calculation result recording, Ventilation calculation result recording, 12-lead analysis recording, CO measurement recording, Frozen waveform recording

Data Management Specifications

  • Trend Data: 3 hours, resolution: 1 s | 120 hours, resolution: 1 min
  • Alarm Events: Up to 200 sets
  • NIBP Measurement Data: 1200 sets
  • Arrhythmia Events: Up to 200 sets
  • 12-lead Analysis Result: Up to 50 sets
